Code-First TypeScript Automation

1import { Machine, StateNode } from "@fkws/klonk";
2import { OpenRouterClient } from "./tasks/common/OpenrouterClient";
3import { Model } from "./tasks/common/models";
4import { TABasicTextInference } from "./tasks/TABasicTextInference";
5import { TASearchOnline } from "./tasks/TASearchOnline";
6
7type StateData = {
8  input: string;
9  output?: string;
10  model?: Model;
11  refinedInput?: string;
12  searchTerm?: string;
13  searchResults?: {
14    results: {
15      url: string;
16      title: string;
17      content: string;
18      raw_content?: string | undefined;
19      score: string;
20    }[];
21    query: string;
22    answer?: string | undefined;
23    images?: string[] | undefined;
24    follow_up_questions?: string[] | undefined;
25    response_time: string;
26  };
27  finalResponse?: string;
28};
29
30const client = new OpenRouterClient(process.env.OPENROUTER_API_KEY!);
31
32const webSearchAgent = Machine.create<StateData>()
33  .addState(
34    StateNode.create<StateData>()
35      .setIdent("refine_and_extract")
36      .setPlaylist((p) =>
37        p // Builder function allows complex types to be assembled!
38          .addTask(new TABasicTextInference("refine", client), (state, outputs) => {
39            // This function constructs the INPUT of the task from the state and outputs of previous tasks
40            const input = state.input;
41            const model = state.model ? state.model : "openai/gpt-5";
42            const instructions =  `You are a prompt refiner. Any prompts you receive, you will refine to `
43                                + `improve LLM performance. Break down the prompt by Intent, Mood, and Instructions. `
44                                + `Do NOT reply or answer the user's message! ONLY refine the prompt.`;
45            return {
46              inputText: input,
47              model: model,
48              instructions: instructions,
49            };
50          })
51          .addTask(new TABasicTextInference("extract_search_terms", client), (state, outputs) => {
52            const input = `Original request: ${state.input}\n\nRefined prompt: ${state.refinedInput}`;
53            const model = state.model ? state.model : "openai/gpt-5";
54            const instructions = `You will receive the original user request AND an LLM refined version of the prompt. `
55                               + `Please use both to extract one short web search query that will retrieve useful results.`;
56            return {
57              inputText: input,
58              model: model,
59              instructions: instructions,
60            };
61          })
62          .finally((state, outputs) => {
63            // The finally block allows the playlist to react to the last task and to modify state data before the run ends.
64            if (outputs.refine.success) {
65              state.refinedInput = outputs.refine.data.text;
66            } else {
67              state.refinedInput = "Sorry, an error occurred: " + outputs.refine.error;
68            }
69
70            if (outputs.extract_search_terms.success) {
71              state.searchTerm = outputs.extract_search_terms.data.text;
72            }
73          }),
74      )
75      .retryLimit(3) // Simple retry rule setters. Also includes .preventRetry() to disable
76                     // retries entirely and .retryDelayMs(delayMs) to set the delay between retries.
77                     // Default is infinite retries at 1000ms delay.
78      .addTransition({
79        to: "search_web", // Transitions refer to states by their ident.
80        condition: async (stateData: StateData) => (stateData.searchTerm ? true : false),
81        weight: 2, // Weight determines the order in which transitions are tried. Higher weight = higher priority.
82      })
83      .addTransition({
84        to: "generate_response",
85        condition: async (stateData: StateData) => true,
86        weight: 1,
87      }),
88    {
89      initial: true,
90    }, // The machine needs an initial state.
91  )
92  .addState(
93    StateNode.create<StateData>()
94      .setIdent("search_web")
95      .setPlaylist((p) =>
96        p
97          .addTask(new TASearchOnline("search"), (state, outputs) => {
98            return {
99              query: state.searchTerm!, // We are sure that the searchTerm is not undefined because of the
100                                        // transition condition.
101            };
102          })
103          .finally((state, outputs) => {
104            if (outputs.search.success) {
105              state.searchResults = outputs.search.data;
106            }
107          }),
108      )
109      .addTransition({
110        to: "generate_response",
111        condition: async (stateData: StateData) => true,
112        weight: 1,
113      }),
114  )
115  .addState(
116    StateNode.create<StateData>()
117      .setIdent("generate_response")
118      .setPlaylist((p) =>
119        p
120          .addTask(new TABasicTextInference("generate_response", client), (state, outputs) => {
121            return {
122              inputText: state.input,
123              model: state.model ? state.model : "openai/gpt-5",
124              instructions:
125                "You will receive a user request and a refined prompt. There may also be search results. "
126              + "Based on the information, please write a professional response to the user's request.",
127            };
128          })
129          .finally((state, outputs) => {
130            if (outputs.generate_response.success) {
131              state.finalResponse = outputs.generate_response.data.text;
132            } else {
133              state.finalResponse = "Sorry, an error occurred: " + outputs.generate_response.error;
134            }
135          }),
136      ),
137  )
138  .addLogger(pino()) // If you add a logger, Klonk will call its
139                     // info(), error(), debug(), fatal(), warn(), and trace()
140                     // methods to emit logs. Built for pino, but you can pass any fitting logger object.
141  .finalize({
142    // Finalize your machine to make it ready to run.
143    // If you don't provide an ident, a uuidv4 will be generated for it.
144    ident: "web-search-agent",
145  });
146
147// ------------- EXECUTION: -------------
148
149const state: StateData = {
150  // The state object is mutable and is passed to the machine and playlists.
151  input: "How do I update AMD graphic driver?",
152  model: "openai/gpt-4o-mini",
153};
154
155// The .run() method executes the machine until it reaches a terminal condition
156// based on the selected mode. For example, 'roundtrip' stops when it returns
157// to the initial state. The original state object is also mutated.
158const finalState = await webSearchAgent.run(state, { mode: 'roundtrip' });
159
160console.log(finalState.finalResponse); // The final state is returned.
161// Or simply:
